Tarot GOPRO T-DZ Vehicle metal three-axis Mounted gimbal is specially designed for GoPro Hero3/3+/4 cameras.Using the full CNC industrial structure with integrated ribbed panels to bring light- weight and high-stability.Built-in independent IMU precise control PTZ attitude, integrated PTZ and servo drive module, support attitude locking, pointing to follow, and the first three kinds of work mode.
Support conventional receiver / S-Bus receiver / PPM receivers / DSM receivers.It's the best choice for professional video and aerial photography enthusiasts.
Assistant software installation requirements: Windows XP; Windows VISTA; Windows 7; Windows 8/10 (32 or 64 bit)
Specifications:
Applicable camera type: GOPRO HERO 3/3+/4
Input Power: 3S-6S Li (11V-26V)
Operating Current: 30mA(@25V)/50mA(@12V)
Stall current: 350mA(@25V)/700mA(@12V)
Attitude control accuracy: ±0.02 degrees maximum controllable speed rotation direction (PAN): ±200°/s
Tilt Direction (TILT): ±200°/s
Roll direction: ±200°/s
Controllable Rotation Range Direction of Rotation (PAN): -125°~+125°
Tilting direction (TILT): -90°~+125°
Roll direction: -35°~+40°
S-Bus/PPM/DSM receiver support working environment temperature: -20°C~+50°C
Maximum dimensions (length, width, height): 230mm * 214mm * 116mm
Package includes:
Three-axis metal head 360g×1
PTZ master control module (36×25×11MM)×1
8P PTZ master control and PTZ main body connection line × 1
5V output, receiver and video line × 1
USB module (27×21×7MM)×1
GoPro charging and video output line × 1
Car charger XT30 female output line (150CM) × 1
XT30 Male × 1
Packing box × 1
