Siyi AK28 Agriculture Drone Transmitter Datalink Videolink 3in1 Radio with LCD screen

SKU: LA0082
0.0 (0)
$499.00 $699.00
CE cetification, TELEC certification
transmitter, datalink and videolink 3in1
great choice for agriculture spraying drones
Received successfully
Coupon Code
CONTINUE SHOPPING
    Please select the information you want X
  • Ships From:
    China
    Please select the information you wantX
Quantity:
  • Siyi AK28 Agriculture Drone Transmitter Datalink Videolink 3in1 Radio with LCD screen
  • Siyi AK28 Agriculture Drone Transmitter Datalink Videolink 3in1 Radio with LCD screen
  • Siyi AK28 Agriculture Drone Transmitter Datalink Videolink 3in1 Radio with LCD screen
  • Siyi AK28 Agriculture Drone Transmitter Datalink Videolink 3in1 Radio with LCD screen
  • Siyi AK28 Agriculture Drone Transmitter Datalink Videolink 3in1 Radio with LCD screen
  • Siyi AK28 Agriculture Drone Transmitter Datalink Videolink 3in1 Radio with LCD screen
  • Siyi AK28 Agriculture Drone Transmitter Datalink Videolink 3in1 Radio with LCD screen
Frequently Bought Together
more
Frequently Bought Together
  • Description

The SIYI AK28 has upgraded to MK32.If you need MK32,please click here.

Siyi AK28 is comes with IUAV OS, a customized drone operating system powered by Andriod. The AK28 integraged with long-distance datalink and videolink comes with an HD FPV camera. It is designed and manufactured with the waterproof and dustproof ability on the industrial level for drone operations in extreme circumstances.With 7" bult-in touchscreen high brightness monitor, you can know the situation in front of the drone in reall time.


Specifications:
Item Brand: SIYI
Item Model: Siyi AK28
Transmission Range: 2 km (effective operation range, ground to ground)
Frequency Band: 2.400-2.483 GHz
Channels: 14 physical channels, 14 output channels
Applicable Models: Planes/Helicopters/Gliders/Quadcopters/Multi-rotors/Vehicles/Boat/Robotics
Compatible Flight Controllers: Open Source Flight Controllers: PIX, APM,BOYING PALADIN V2,TOPXGUN T1-A,WOOZOOM THEONE-A – A,EFY FINIX200M,JIYI K3A K++,CFUAS C1-A


FPV CAMERA & NAVIGATION LIGHT
Camera Angle: FOV 120°
Dimension (Videolink Module): 106*25*41 mm
Item Weight: 108 g
Power Consumption (Navigation Light): 8 W
Luminous Flux: 120-140lm/W
LED Type: Translucent
LED Searching Angle: 120°
Operation Temperature: -10℃ to 55℃


GROUND STATION (TRANSMITTER)
Device for Display: 7", Android OS, 2G RAM + 16G ROM
Dimensions: 308 x 148 x 72 mm
Item Weight: 1100 g
Battery Type: 13000 mAh LiPo 1S 3.7V
Battery Working Temperature: 0℃ ~ 55℃
Charging: Micro-USB 5V/2A
Working Time: >9 hrs


SKY STATION (RECEIVER)
Signal Output: 14 Channels of S.BUS, 5 channels of PWM
Datalink Port (to FC): UART, CAN (optional)
Dimensions (without antennas): 59 x 59 x 16 mm
Item Weight (without antennas): 50 g
Antenna Gain: 5 dBi
Working Voltage: 15 - 50 V
Telemetry Voltage: 15 - 50 V
Operating Temperature: -10℃ ~ 55℃

siyi ak28 radio

siyi radio

siyi radio

agriculture drone radio

siyi ak28 transmitter

radio for drones

siyi ak28

ak28 transmitter

siyi radio review

Note: When you place the order, Plese leave the following information in the comment bar: 1.  Will you use the radio on Multirotors, Agriculture drone or airplanes or other?  2. What flight controller do you use? (For different FC, we will send the proper compatible cables with the radio) 3. Will you install the Ground Station ? If yes, what ground station will you use? Thanks.
