Tarot Electronic Retractable Landing Gear Control System Controller TL8X002

SKU: TL8X002
0.0 (0)
$11.50 $0.00
Received successfully
Coupon Code
    Please select the information you want X
  • Ships From:
    Please select the information you wantX
  • Tarot Electronic Retractable Landing Gear Control System Controller TL8X002
Frequently Bought Together
Frequently Bought Together
  • Description

Product Description:
Tarot newly developed high performance electric retractable landing skid controlling system could be used on following items:
Electric landing gear controller TL8X002
New electric landing gear TL65S01
Small electric landing gear TL65B43
Small electric landing gear group TL65B44
Medium electric landing gear TL8X003
X-series electric landing gear TL96030
Large electric landing gear TL4N001
Large elecric landing gear group TL4N002

Supply voltage:
Operating voltage: 3S-6S (12.6V --- 25.2V)
Minimum voltage: 10V
Maximum voltage: 26V

Product Function Description:
1. reverse power protection: The power of positive and negative polarity will not damage the landing gear control panel.
2. the receiver is connected Description: Enter a channel through 3P ​​line even ordinary receiver, the signal for the PWM, pulse width of zero value 1520us, the pulse width is greater than 1520us for landing gear, the pulse width is less than 1520us is closed landing gear.
3. the receiver connection instructions: initial power-up if there is no receiver signal, the indicator flashes rapidly until the receiver detects the signal.
4. Power Protection: After initial power-up if the receiver is close to the landing gear of the action, landing gear does not respond, and the indicator light flashes slowly, until the receiver instruction becomes the landing gear, the light goes out.
5. work instructions: When the retractable landing gear operation is being performed, the indicator lit until the landing gear completely stopped, the light goes out.
6. runaway protection: When the work process, after the loss of receiver signal, the landing gear will automatically put down.

How to check whether the motor positive and negative reversed:
When the landing gear to work properly, remove the receiver signals to the control panel to enter the failsafe state, if
the state is to put the landing gear then the positive and negative electrical wiring is correct, otherwise described motor
positive and negative reversed.
Product Specifications:
Electric retractable tripod control x 1 (47 x 32 x 9.5MM) 13G
