FEETECH FT810BL 10kg High Torque Digital Servo with Metal Gear RC Car Crawler Upgrade Brushless Servo

Name: FEETECH FT810BL 10kg High Torque Digital Servo with Metal Gear RC Car Crawler Upgrade Brushless Servo
Brand: ARRISHOBBY
SKU: DF0035
Price: 41.99 USD
Availability: InStock

SKU: DF0035

0.0 (0)

$41.99

great upgrade servo for car,crawler and etc
great robot servo
10kg high torque servo

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites

1/1

Description

FEETECH FT810BL 10kg brushless sero is great for RC cars, boats, robots or where the standard servo used.
It can be used in main educational robots, such as quadruped robots, humanoid robots, snake robots and etc.

Specifications:

Model：	FT810BL
Product Name:	7.4V 10kg.cm PWM High Torque Digital Servo with Metal Gear
Storage Temperature Range	-30℃～80℃
Operating Temperature Range:	-20℃～60℃
Size:	A：54.45mm B：20mm C: 38.95mm
Weight:	84± 1g
Gear type:	Steel
Limit angle:	NO limit
Bearing:	Ball bearings
Horn gear spline:	25T/5.9mm
Gear Ratio：	1/188
Case:	Alumi num
Connector wire:	30CM
Motor:	Brushless Motor
Operating Voltage Range:	6V-7.4V
Idle current (atstopped)	[email protected]
No load speed:	0.07sec/60°@7.4V
Runnig current(at no load) :	[email protected]
Peak stall torque:	[email protected]
Rated torque:	[email protected]
Stall current:	[email protected]
Command si gnal	Pulse width modification
Amplifier type	Digital comparator
Pulse width range	500~2500 μ sec
Stop position	1500 μ sec
Running degree	180°(at 500→2500μsec)
Dead band width	≤4 μ sec
Rotating direction	Counterclockwi se (在1500→2000 μ sec)

Drawings:
