Description

Boying Draco series industry drone flight control system has comprehensive flight status monitoring and alarm functions and a complete emergency protection mechanism. It provides highly integrated ground station software XUAV, which has functions such as flight data monitoring, drone status display, abnormal status alarm, flight remote control, electronic map, route planning, load display and control.

It is also closely integrated with the remote control device, the control mode switching and other operations of the Boying industry system can be performed through the remote control, so as to ensure that the operator can intervene in time during the take-off and landing of the multi-rotor drone to ensure flight safety.

It provides powerful route planning capabilities and flexible mission control functions. Users can easily formulate diversified flight missions using the ground station software.

The BoYing industry flight control system integrates high-precision inertial and satellite navigation sensors. The sensor data is pre-processed, drift compensated within the full temperature range, and data fused. It can obtain flight attitude, position coordinates, working status and other parameters in real time, and complete high-precision attitude and route control of multi-rotor UAV platforms.

Specifications:
Item Brand: BOYING
Item Model: Draco V1

Basic parameters (interface)
Power supply: 1
LED indicator: 1
Gps module: 1
Remote control receiver SBUS: 1
Electric adjustment channel: 8
Auxiliary channel: 4 outputs, 1 adjustable
CAN: 2
RTK interface: 1
Data transmission interface: 1
Payload interface: 1
4G interface: 1
Type-cUSB interface: 1
Liquid level interface: 1

Physical parameters
Size: 67mmx44mmx27mm
Weight: 68g
Operating temperature: -20~70℃
Operating humidity: 5%~95%
Power module: 6-16S or 12-28S

Package Included:
Boying Draco V1 Main Controller *1
GPS module *1
GPS module bracket *1
Power module *1
Power module output line *1
Flight indicator *1
Digital transmission/bluetooth universal connection line *1

Optional Parts: 4G module, CAN Module, RTK module, front and rear obstacle avoidance radar, Omnidirectional obstacle avoidance radar, terrain-imitation radar, enhanced positioning module, single Beidou positioning module...
